| Monitor Display Spec |
Display size |
39.62cm / 15.6″ Diagonal White LED-Backlight |
| Brightness(Typical) |
220cd/m2 |
| Contrast(Typical) |
500:1 |
| Pixel Pitch |
0.252(H) x 0.252(V) mm |
| Resolution (H x V) |
1366 x 768 |
| Aspect Ratio |
16:9 |
| Response Time(Typical) |
12ms |
| View Angles LR,UD(CR>10) |
110° H / 85° V (CR > 5); 90° H / 60° V (CR >10) |
| Panel Surface |
Anti-Glare |
| Display Colors |
262k Colors |
| PC Input Range |
Horizontal Freq. |
30 to 61KHz |
| Vertical Freq. |
56 to 75Hz |
Max. display frequency
(Resolution H*V/Fv) |
1366 x 768 / 60 Hz |
| Interface |
Input 1 |
D-Sub (VGA x 1 |
| Input 2 |
HDMI x 1 |
| Input 3 |
NA |
| Input 4 |
NA |
Output
Terminal |
Earphone |
NA |
| Speakers |
Yes 1.5W x 2; Earphone Jack (Audio Out) |
| Power |
Consumption(Typical) |
On: 6W; Stand-by: 0,2W; Off: 0,2W |
| AC Power Range |
Input: AC 100 ~ 240 Volt; 50 ~ 60 Hz |
Power Mode
Indicator Light |
Power on : Green (LED)
Power Saving: Green Flicker (LED) |
Operating
Condition |
Temperature |
5 ~ 35℃ |
| Humidity |
20% ~ 70%, non-condensing |
| Physical |
Dimension
(W*D*H) |
376 x 150 x 302 mm (W x D x H) with Stand |
Packing Dimension
(W*D*H) |
449 x 108 x 360 (W x D x H) |
| Net Weight |
1.2kg |
| Gross Weight |
2.0kg |
| Bezel Type |
TBC |
| Tilt |
-30° ~ + 125° |
| High Adjustable Arm |
NA |
| Swivel |
NA |
| Pivot |
NA |
| Kensington Lock |
NA |
| VESA Mounting |
100 x 100 mm |
| Controls |
Front Control |
Menu, Bri (+), Vol(-), Input/Enter, Power |
| On Screen Display |
12 OSD Languages |
| Color |
Warm, Natural, Cool, User Mode |
| Preset Mode |
PC, Movie, Game, Modes |
| |
Accessory |
Power Cord; HDMI Cable; Warranty Card; Quick Start Guide |
