HL 205 ABB

SKU: HL 205 ABB Category:
  • LED Backlight Monitor
  • 1600 x 900 HD + Resolution
  • 80,000,000:1 Active Contrast
  • 5ms Response Time
  • VGA Inputs
  • Low Power Consumption
  • Multi-Video Modes: PC/Movie/Game/ECO
  • Tilt and Wall-Mountable (VESA)
  • ECO Friendly
LCD Panel Display size 19.5″ Diagonal White LED-Backlight
Brightness(Typical) 250cd/m2 (Typical)
Contrast(Typical) 1000:1 (Typical)
80,000,000:1 (Active Contrast )
Pixel Pitch 0.2712(H) * 0.2626(V)
Resolution (H x V) 1600 x900
Aspect Ratio 16:9
Response Time(Typical) 5ms
View Angles LR,UD(CR>10) HV  170°/160°
Panel Surface Anti-glare
Display Colors 16.7M colors
PC Input Range Horizontal Freq. 30 to 81KHz
Vertical Freq. 56 to 75Hz
Max. display frequency
(Resolution H*V/Fv)
1600 x900  / 60hz
Interface Input 1 D-Sub x 1
Power Consumption(Typical) On: 25 W
Standby<=0.5W, Off<=0.5W
AC Power Range AC 100~240V
Power Mode
Indicator Light
Power on : Green (LED)
Power saving : Green Flicker (LED)
Operating
Condition
Temperature 5℃ ~ 35℃
Humidity 20% ~ 85%, non-condensing
Physical Dimension
(W*D*H)
478*353*180mm
Packing Dimension
(W*D*H)
514*355*105mm
Net Weight 2.6KG
Gross Weight 3.4KG
Tilt -5∘~15∘
Kensington Lock Yes
VESA Mounting 75x 75mm
Controls Front Control Menu, -, +, Auto, Power
On Screen Display 11(English, French, German, Italian, Simplified Chinese, Traditional Chinese, Korean, Japanese, Espanola,  Portuguese, Russian )
Color 9300,6500,5500, User Mode
Preset Mode PC, Movie, Game  Modes
Accessory Power Cable Yes
VGA Cable (1.5M) Yes
Warranty card Yes, HSD format
User Manual(e-file) Yes, HSD format
Quick Start Guide(Paper) Yes, HSD format
Color Plan Arm / Base /Bezel / Rear Cover – Black Texture
Carton Box Brown carton, HSD format
Certification CE
