| Monitor Display Spec |
Display size |
54.6cm / 21.5″ Diagonal Wide LED |
| Brightness(Typical) |
250cd/m2 |
| Contrast(Typical) |
1000:1
80,000,000:1 (active contrast) |
| Pixel Pitch |
0.248(H) x 0.248(V) |
| Resolution (H x V) |
1920*1080 |
| Aspect Ratio |
16:9 |
| Response Time(Typical) |
5ms |
| View Angles LR,UD(CR>10) |
H/V 170°/160°(CR>10) |
| Panel Surface |
Anti-glare |
| Display Colors |
16.7M Colors |
| PC Input Range |
Horizontal Freq. |
31kHz to 83kHz |
| Vertical Freq. |
56Hz to 75Hz |
Max. display frequency
(Resolution H*V/Fv) |
1920*1080/ 60HZ |
| Interface |
Input 1 |
D-Sub x 1 |
| Input 2 |
DVI-D(with HDCP) x 1 |
| Input 3 |
PC audio x 1 |
| Input 4 |
HDMI x 1 |
Output
Terminal |
Earphone |
Yes |
| Speaker(Typical) |
1.5W x 2 |
| Power |
Consumption(Typical) |
On: 18.8 W
Standby<=0.5W, Off<=0.5W |
| AC Power Range |
AC 100~240V, 50~60Hz |
Power Mode
Indicator Light |
Power on : Green (LED)
Power saving : Green Flicker (LED) |
Operating
Condition |
Temperature |
5℃ ~ 35℃ |
| Humidity |
20% ~ 85%, non-condensing |
| Physical |
Dimension
(W*D*H) |
512*203*390mm |
Packing Dimension
(W*D*H) |
572*152*452mm |
| Net Weight |
4.7Kg |
| Gross Weight |
5.4Kg |
| Bezel Type |
Matt |
| Tilt |
-5∘~ 15∘ |
| Kensington Lock |
Yes |
| VESA Mounting |
100 x 100mm |
| Controls |
Front Control |
Menu, Bri (+), Vol(-) Input/Enter, Power |
| On Screen Display |
HSD OSD format, 12 language : EN,TC,DE,FR,ES,IT,PT,NL,SC,JS,KR,Russian |
| Color |
WARM,NATURE,COOL, User Mode |
| Preset Mode |
PC, Movie, Game, ECO Modes |
| Accessory |
Power Cable(1.5m) |
Yes |
| VGA Cable(1.5m) |
Yes |
| Audio Cable(1.5m) |
Yes |
| DVI Cable(1.5m) |
Optional |
| User Manual(CD) |
Yes, HSD format |
| Quick Start Guide(Paper) |
Yes, HSD format |
| Certification |
CE, CB,GS,EPA6.0,HDMI,TCO 6.X |
