HL 226 HPB

SKU: HL 226 HPB Category:
  • LED Backlight Monitor
  • 1920 x 1080 WUXGA Resolution (54,6cm / 21.5” Diagonal)
  • Full HD 1080P
  • 80,000,000:1 Active Contrast
  • 5ms Response Time
  • VGA+DVI+HDMI Compatible Inputs
  • Multi-Video Modes: PC / Movie / Game / ECO
  • Built-In Stereo Speakers
  • Tilt and Wall-Mountable (VESA)
  • Low Power Consumption
Monitor Display Spec Display size 54.6cm / 21.5″ Diagonal Wide LED
Brightness(Typical) 250cd/m2
Contrast(Typical) 1000:1
80,000,000:1 (active contrast)
Pixel Pitch 0.248(H) x 0.248(V)
Resolution (H x V) 1920*1080
Aspect Ratio 16:9
Response Time(Typical) 5ms
View Angles LR,UD(CR>10) H/V 170°/160°(CR>10)
Panel Surface Anti-glare
Display Colors 16.7M Colors
PC Input Range Horizontal Freq. 31kHz to 83kHz
Vertical Freq. 56Hz to 75Hz
Max. display frequency
(Resolution H*V/Fv)
1920*1080/ 60HZ
Interface Input 1 D-Sub x 1
Input 2 DVI-D(with HDCP) x 1
Input 3 PC audio x 1
Input 4 HDMI x 1
Output
Terminal
Earphone Yes
Speaker(Typical) 1.5W x 2
Power Consumption(Typical) On: 18.8 W
Standby<=0.5W, Off<=0.5W
AC Power Range AC 100~240V, 50~60Hz
Power Mode
Indicator Light
Power on : Green (LED)
Power saving : Green Flicker (LED)
Operating
Condition
Temperature 5℃ ~ 35℃
Humidity 20% ~ 85%, non-condensing
Physical Dimension
(W*D*H)
512*203*390mm
Packing Dimension
(W*D*H)
572*152*452mm
Net Weight 4.7Kg
Gross Weight 5.4Kg
Bezel Type Matt
Tilt -5∘~ 15∘
Kensington Lock Yes
VESA Mounting 100 x 100mm
Controls Front Control Menu, Bri (+), Vol(-)  Input/Enter, Power
On Screen Display HSD OSD format, 12 language  : EN,TC,DE,FR,ES,IT,PT,NL,SC,JS,KR,Russian
Color WARM,NATURE,COOL, User Mode
Preset Mode PC, Movie, Game, ECO Modes
Accessory Power Cable(1.5m) Yes
VGA Cable(1.5m) Yes
Audio Cable(1.5m) Yes
DVI Cable(1.5m) Optional
User Manual(CD) Yes, HSD format
Quick Start Guide(Paper) Yes, HSD format
                                  Certification CE, CB,GS,EPA6.0,HDMI,TCO 6.X
