HU 282 PPS

SKU: HU282PPS Category:
  • 28” 16:9 LED Backlight Monitor
  • 4K*2K 3840 x 2160 Resolution
  • Toughened Glass
  • 5ms Fast Response Time
  • Display port
  • HDMI x 2, DVI-D
  • Built-In Stereo Speakers
  • Tilt and Wall-Mountable (VESA)
  • Multi-Video Modes
  • ECO Friendly
LCD Panel Display size 28″ Diagonal White LED-Backlight
Brightness(Typical) 280cd/m2
Contrast(Typical) 1000:1
(Dynamic: 5,000,000:1)
Pixel Pitch 0.16(H) x 0.16(V) mm
Resolution (H x V) 3840*2160@60Hz
Aspect Ratio 16:9
Response Time(Typical) 5ms
View Angles LR,UD(CR>10) H/V 170°/160°(CR>10)
Panel Surface Toughened protective glass
Display Colors 1.073Bcolors
PC Input Range Horizontal Freq. 30~80KHz
Vertical Freq. 60~75Hz
Max. display frequency
(Resolution H*V/Fv)
3840*2160@60Hz
Interface Input 1 DP*1
Input 2 DVI*1
Input 3 HDMI *2
Input 4 Audio in ×1
Output
Terminal
Earphone 3.5 mm mini-jack
Speaker(Typical) 8Ω/3W
Power Consumption(Typical) On: <=38W
Standby<=0.5W, Off<=0.5W
AC Power Range 100 ~ 240 VAC / 50 ~ 60 Hz
Power Mode
Indicator Light
Power on : Green (LED)
Power saving : Green flicker (LED)
Operating
Condition
Temperature 0℃ ~ 40℃
Humidity 0~70%RH
Physical Dimension
(W*D*H)
680.1mm(W)*192mm(D)*504.1mm(H)
Packing Dimension
(W*D*H)
735mm(W)*150mm(H)*572mm(D)
Net Weight 7.2 kgs
Gross Weight 8.7 kgs
Bezel Type Glossy
Tilt -5˚~15˚
Kensington Lock YES
VESA Mounting 75*75 mm
Controls Front Control Menu,DOWN,UP,EXIT,Power
On Screen Display 6 OSD language : EN,DE,FR KR,Traditional Chinese ,Simplified Chinese
Color WARM,COOL,USER MODE
Accessory Power Cable(1.5m) Yes
VGA Cable(1.5m) N/A
Audio Cable(1.2m) YES
DVI Cable(1.5m) YES
User Manual(CD) Yes
Quick Start Guide(Paper) Yes
Certification CE,Energy level, HDMI (apply)
Energy Label 55 kWh /annum

  • 1530009265wpdm_1462903329-hu282pps___datasheet__fr_.pdfDownload
  • 1462903329-hu282pps___datasheet__de_.pdfDownload
  • 1462903329-hu282pps___datasheet.pdfDownload
